Hand Brakes: 5 Year Warranty - Made in USA

Lifetime Warranty
National offers these hand brakes with a great deal of pride. A simple design, utmost strength with a long life of dependable service. Streamline designed for fast, accurate bending — even for the inexperienced workman. Heavy steel body construction with extra heavy tie rods for perfect alignment. Precision bearings on the apron assures you of a smooth operating brake. These brakes come with a full three year warranty
  Specifications
Model N4812 N7212 N9616
Capacity
(Yield Strength 30,000 lbs. @ rated capacity)
Mild Steel
12 Gauge: 2.7mm
Stainless
16 Gauge: 1.6mm
Mild Steel
12 Gauge: 2.7mm
Stainless
16 Gauge: 1.6mm
Mild Steel
16 Gauge: 1.6mm
Stainless
20 Gauge: .9mm
Bending Length 49”/1245mm 73”/1854mm 97”/2464mm
Shipping Weight 1050lbs/476kgs 1800lbs/816kgs 1600lbs/726kgs
Floor Space w/ Gauges 95” x 27” x 55”
2413 x 686 x 1397mm
129” x 27” x 59”
3277 x 686 x 1499mm
143” x 27” x 55”
3632 x 686 x 1397mm

  Specifications
Model N9618 N9614 N12018
Capacity
(Yield Strength 30,000 lbs. @ rated capacity)
Mild Steel
18 Gauge: 1.3mm
Stainless
22 Gauge: .85mm
Mild Steel
14 Gauge: 1.9mm
Stainless
18 Gauge: 1.2mm
Mild Steel
18 Gauge: 1.3mm
Stainless
22 Gauge: .85mm
Bending Length 97”/2464mm 97”/2464mm 121”/3073mm
Shipping Weight 1500lbs/680kgs 1750lbs/794kgs 2650lbs/1202kg
Floor Space w/ Gauges 153” x 27” x 59”
3886 x 686 x 1499mm
153” x 27” x 59”
3886 x 686 x 1499mm
177” x 29” x 59”
4496 x 737 x 1499mm

  Specifications
Model N12016 N12014 N14418
Capacity
(Yield Strength 30,000 lbs. @ rated capacity)
Mild Steel
16 Gauge: 1.6mm
Stainless
20 Gauge: .9mm
Mild Steel
14 Gauge: 1.9mm
Stainless
18 Gauge: 1.2mm
Mild Steel
18 Gauge: 1.3mm
Stainless
22 Gauge: .85mm
Bending Length 121”/3073mm 121”/3073mm 145”/3683mm
Shipping Weight 2800lbs/1270kgs 3200lbs/1452kg 3450 lbs/1553kgs
Floor Space w/ Gauges
w/ Counterweight
177” x 29” x 59”
4496 x 737 x 1499mm
177” x 29” x 59”
4496 x 737 x 1499mm
201” X 29 X 59”
5105 x 737 x 1499mm
